3720 Part-turn Electric Actuator For Ventilation Valves

3720 Quarter-turn Electric Actuator

Functions and features of 3720 series intelligent electric actuator:

Control module adopts advanced hybrid integrated circuit, with powerful functions.
Non-intrusive remote control operation function: parameter adjustment and setting without opening the cover, on-site manual operation, output contact feedback and display of manual/automatic working status.
The control module adopts menu setting, simple and convenient parameter setting and function adjustment.
Input signal setting function: choose analog control (DC4~20mA) or switching control (AC220V) according to the working condition, wiring is independent and does not interfere with each other, both can output DC4~20mA feedback signal.
Valve position display and fault alarm function with input signal and valve position display function, and signal, manual/automatic, positive/reverse action, limit and fault indicator.
Action time, action number memory function.
Calibration function of input signal and feedback signal to improve control accuracy.
Anti-interference function: set reverse action delay time to avoid reverse shock.
Zero point and stroke calibration, convenient and accurate, can be set at any position.
Four state settings for SMS: fully closed, fully open, self-setting (full stroke), and keep in place.
Electronic limit function: with in-place contact feedback
Fault self-diagnosis function: can self-diagnose the fault phenomenon to protect the actuator.
Overload protection function: overload protection time can be set according to the need.
Temperature protection function: temperature protection switch is installed inside the motor to protect the motor from being burned.
Embedded click structure, reasonable overall design, compact mechanism, small size, pro-weight and good heat dissipation.
The actuator is self-locking after power failure.

372: Design serial number, 372 is 3720 series intelligent type electric actuator

L: L is the Linear-turn actuator, R is the quarter-turn actuator

S: S is ordinary type actuator

A: A denotes dimension specification, denotes with A, B, C

08: It represents output force or output torque, see model and specifications

※: The symbol for the selection

J: Quarter-turn actuator with crank with base(options)

Main technical parameters of 3720 series intelligent actuator

Model Specification Table

Performance Indicators

Company Introduction

Founded in 2014, Freya is mainly engaged in fluid control products and services such as actuators, valve electric devices, and electric valves. It focuses on the field of process industry and has long been committed to providing professional According to the actual working conditions, through the necessary on-site surveying and mapping and technical clarification, we provide customers with safe, economical and environmentally friendly selection and design, supply strictly in accordance with the contract requirements and guide the installation and commissioning, and hand over for use after reaching the standard. Thanks to the trust of the vast number of users, through long-term and extensive on-site services and the effective accumulation of technical experience, the company accurately understands the real needs, pain points and expectations of equipment manufacturers of users and the market. Intelligent electric actuator, reliable, durable, easy to use, cost-effective, and guaranteed service. Being close to users, providing full-process services, comprehensive services, value-added maintenance services, and escorting users' production is our differentiated advantage. Freya SD intelligent electric actuators and valve electric devices provide a two-year warranty after installation and commissioning, and free after-sales service for life. Technical quality and commercial credit are the foundation of the company's survival and the two wheels that drive the company's development. Users feel at ease, peace of mind, and happiness, which is the only criterion for evaluating our work effect and demonstrating the value of existence. Many of the company's customers are located in thermal power, petrochemical, coal chemical, water treatment and other fields, all over the country, including more than 100 end users belonging to the five major power generation groups, the three major nuclear power groups, Sinopec, PetroChina and local energy groups.
